Why Austin clay and limestone move gate posts

Nothing about a gate that scrapes the pavement in August and clears it in March is a hinge problem, and the running record austin iron gates preflight sim holds on these cases points to the soil. Gates in Austin, TX sit on two different kinds of ground, split roughly by the Balcones Fault, and each one moves a post in its own way.

Clay east of the fault

East of the Balcones Escarpment the soil is shrink-swell clay. It swells with rain and shrinks in drought, and a post set in a shallow concrete plug is pushed and pulled by that movement through the year. A hinge post that leans a half inch toward the leaf in summer drags the gate on the ground, even though the gate itself never changed.

Limestone to the west

The hills west of the fault have thin soil over limestone. A post hole stops where the rock starts, so a footing may be only a foot or so deep if it is not drilled through. Rock holds a post firmly in place, but a short footing on a slope can still rotate under a heavy leaf, and a fractured seam can let water run under the concrete and wash it out.

Footing depth and shape

A good footing is deeper than it is wide and widens at the bottom, so it resists being pushed out of the ground by swelling clay. Rebar cages tie the concrete together. Where rock is shallow, a drilled hole with a pinned steel post is worth the extra labor. A steel post wants a base plate or a fully buried section, never a thin pipe sunk into a shallow hole.

What sag is telling you

A leaf that drops at the latch end points to a hinge post that has moved, a cracked weld at the top hinge, or a frame that was never braced. A diagonal brace running from the bottom hinge to the top latch corner holds the leaf square. A gate that drags in summer and clears in winter points almost always to the clay, not the metal.

Fixing it without a rebuild

Adjustable hinges buy a few seasons, and shimming the bottom hinge can bring a leaf back to level. When a post has moved several inches, the cleaner fix is to cut it out and reset it in a new footing, with the gate hung only after the concrete has cured. A gate opener should not be asked to drag a leaf the ground is holding back.
